AT-2716POE Fast Ethernet Fiber & PoE Adapter Installation and User’s Guide
80
Testing Network Connectivity
The following section describes how to test network connectivity for
Windows XP, Windows Vista, and Windows 7 networks. Use the ping
command to determine if network connectivity is working.
Note
When using forced link speeds, make sure that both the adapter and the
switch are forced to the same speed. Or, make sure both partners are
configured for Auto-Negotiation.
To test the network connectivity for the Windows driver software, do the
following:
1. Select Run from the Windows Start Menu.
The Run command window opens, as shown in Figure 40.
Figure 40. Run Command Window
2. Type cmd and click OK.
3. Type ipconfig /all
The command window opens, as shown in Figure 41 on page 84.
