x510 Series Installation Guide for Stand-alone Switches
79
Figure 40. Status of a Stacking Slot When VCStack is Disabled
The switch displays the message in Figure 41 if VCStack is not
disabled, in which case you need to disable it by performing the
commands in “Disabling VCStack” on page 76.
Figure 41. Status of a Stacking Slot When VCStack is Enabled
awplus>show interface port1.0.51
Interface port1.0.51
Scope: both
Link is DOWN, administrative state is UP
Thrash-limiting
Status Not Detected, Action learn-disable, Timeout 1(s)
Hardware is Ethernet, address is 0015.774f.ed30
index 5051 metric 1 mru 1500
configured duplex auto, configured speed auto, configured polarity auto
SNMP link-status traps: Disabled
input packets 0, bytes 0, dropped 0, multicast packets 0
output packets 0, bytes 0, multicast packets 0 broadcast packets 0
Time since last state change: 0 days 00:42:49
awplus# show interface port1.0.51
%Can’t find interface port1.0.51
awplus#
