Page 19
x510 Series Installation Guide for Stand-alone Switches
19
Front and Back Panels
The front panels of the x510 Series switches are shown in Figure 1 and
Figure 2 on page 20.
Figure 1. Front Panels of the AT-x510-28GTX and AT-x510-28GPX
Switches
AT-x510-28GPX
AT-x510-28GTX
10/100/1000Base-T Ports
SFP+ Slots
Management
Panel
SFP+ or
Stacking Slots
SFP+ Slots
Management
Panel
SFP+ or
Stacking Slots
10/100/1000Base-T Ports
with PoE
