Page 33
x510 Series Installation Guide for Stand-alone Switches
33
LEDs
Here are descriptions of the LEDs.
LEDs for the
Twisted Pair
Ports
The twisted pair ports on the AT-x510-28GTX and AT-x510-52GTX
Switches have two LEDs that display link, activity and duplex mode
information. The LEDs are shown in Figure 6.
Figure 6. LEDs for the 10/100/1000Base-T Ports on the AT-x510-28GTX
and AT-x510-52GTX Switches
The LEDs are described in Table 6 on page 34.
Link/Activity
LED
Duplex Mode
LED
Duplex Mode
LED
Link/Activity
LED
