Installation – APC SILCON 10-40KW 400V UPS User Manual
Page 9
Installation
990-4050
Installation Guide APC Silcon 10-40kW 400V UPS
9
Cabinets
600 mm wide
10-20kW
with 1xBP l
1400 mm
10-20kW
with 2xBP l
800 mm wide
1400 mm
1000 mm wide
10-20kW
with 3xBP l
40kW
without batteries
600 mm wide
1000 mm wide
1400 mm
40kW with 2xBP l
1400 mm
1400 mm
1400 mm
APC Isolation
Transformer module
10-80kW
600 mm wide
Battery cabinet
for 1xBP ll
1400 mm
1000 mm wide
Battery cabinet
for 1xBP lll
1400 mm
800 mm wide
