8 Installation Guide APC Silcon 10-40kW 400V UPS
990-4050
Installation
3.0 Installation
3.1 Requirements on Site
All system parts are accessible from front or top of UPS. Cable entries are accessible from
bottom. A 1m free space on all sides should be allowed during installation. Once the system is
installed it may be placed close to walls as long as free space is allowed for system doors to open.
(Per applicable national and/or local codes.)
For ventilation and service purposes allow for free space of minimum 1m above the unit or per
national and/or local codes and in front of UPS. Never install systems in direct sunlight.
3.1.1 Cabinet Dimensions H*xWxD - 1400xWx800 [mm]. Width as in below table:
* H is 1500 mm for optional IP31 cabinets
* BP I = Battery Pack I = 1 x 64 x 7 Ah batteries
** BP II = Battery Pack II = 1 x 64 x 24Ah batteries
*** BP III = Battery Pack III = 1 x 64 x 38 Ah batteries
NOTICE!
For reliability reasons do not stand on the UPS. keep the UPS cabinet surface free of any objects.
Width
Without
Batteries
[mm]
Width With Built-in Batteries
[mm]
Width for Separate
Battery Cabinets
[mm]
UPS 1xBP I* 2xBP I* 3xBP I* 1xBP II** 1xBP III***
10kW 600 600 800 1000 1x800 1x1000
20kW 600 600 800 1000 1x800 1x1000
40kW 600 1000 1x800 1x1000
