Options/accessories – APC SILCON 10-40KW 400V UPS User Manual
Page 59
Options/Accessories
990-4050
Installation Guide APC Silcon 10-40kW 400V UPS
59
6.2
Service Bypass Panel for Parallel Redundant Operation
Service Bypass Panel (SBP)
Mains Supply
System Output
Control
cables
Q003
Q004
Q001b
Q001a
Q002b Q002a
APC Silcon
400V UPS
X020
X021
X020
X021
APC Silcon
400V UPS
Battery
Battery Breaker/
Fuse Box
