51 AXIS 240Q - Technical Specifications
Technical Specifications
Item Specification
Model • AXIS 240Q: Four port video server
Also available as Video Rack Solution
Video compression • Motion-JPEG.
• Single snapshot JPEG images.
Resolutions • 4CIF, 2CIFExp, 2CIF, QCIF
• max 704x480 (NTSC) 768x576 (PAL)
• max 160x120 (NTSC) 176x144 (PAL
Frame rate • Up to 6/5 (NTSC/PAL) frames per second per channel
Video streaming • Motion JPEG
• Controllable frame rate and bandwidth
Image settings • Compression levels: 11
• Rotation: 90º, 180º, 270º
• Aspect ratio correction
• Color: Color, black 6 white
• Overlay capabilities: Time, date, text or image
Security • Multi-user password protection.
• IP address filtering.
• HTTPS (SSL/TLS) encryption.
Users • 20 simultaneous users
Pan/Tilt/Zoom • PTZ support for remote camera control. Please see www.axis.com for information
about supported devices.
Terminal connector - I/O
ports and connections
• 4 digital alarm inputs
• 4 digital output transistors (max 24V, 0.1 A)
• RS-485 serial port
• Alternative power
D-Sub connector • RS-232 serial port. Max 115 Kbit/s.
Network connector • Ethernet 10BaseT/100BaseTX, connected via CAT 5 network cable to RJ-45
network socket.
Processors and memory • ARTPEC-2 compression chip
• ETRAX-100 LX (32-bit RISC, 100MIPS CPU)
• 32 MB RAM
• 8 MB Flash memory
Power • External AXIS PS-K Power adapter (included), 9V DC, 9W.
• Alternative power connection via terminal connector; 7-20V DC, max 7W.
Operating Conditions • Temp: 5 o C (41 o F) to 50 o C (122 o F).
• Humidity: 20-80% RH (non-condensing).
Minimum web browsing
requirements
• Pentium III CPU 500 MHz or higher, or equivalent AMD.
• 128 MB RAM.
• AGP graphic card, Direct Draw, 32 MB RAM.
• Windows XP, 2000, NT4.0, ME or 98.
• DirectX 9.0 or later.
• Internet Explorer 6.x or later.
• For other operating systems and browsers, please see www.axis.com/techsup.
