T H E C O N T I N U O U S P O W E R C O M P A N Y
41
Table 13: ALARMS AND FAULTS
Alarms/Faults
Description
Heat Sink is Hot Heat Sink on main Board temperature too high.
Input is bad AC input to UPS is not within limits.
Output Strange Bad UPS output.
System Overload Load is higher than UPS rated load.
Bypass Failure Bypass Line failed.
Charger Failure Charger not functioning properly.
Fan Fail Fan not functioning properly.
Fuse Failure Open Fuse in system.
Sleep Alarm UPS in sleep mode.
General Fault UPS component failure.
All Outputs Off Output not present.
Shut Off Pending A shutdown command has been activated.
Shut Off Imminent UPS is preparing to shutdown.
System Shutdown
UPS system switch turned Off.
Table 14: DEFAULT SETTINGS
Relay to Rule Rule’s Parameters
Relay Rule Rule Parameters
1 01-On_Batt 02-Low_Bat_1 40%
2 02-Low_Bat_1 03-Bat_Timer_1 02:00:00
3 02- Low_Bat_1 04-Alarms_1 All enabled
4 03-Batt_Timer_1 05-Faults_1 All enabled
5 03-Batt_Timer_1 06-Low_Bat_2 50%
6 04-Alarms_1 07-Bat_Timer_2 01:23:45
7 14-Fan_Ctrl_1 08-Alarms_2 All enabled
8 00-Relay Off 09-Faults_2 All enabled
10-Low_Bat_3 60%
11-Bat_Timer_3 01:01:01
12-Alarms_3 All enabled
13-Faults_3 All enabled
14-Fan_Ctrl_1 27/21
15-Fan_Ctrl_2 27/21
