T H E C O N T I N U O U S P O W E R C O M P A N Y
12
1.4 Summary Of Connectors – Bypass Box
Figure 2: BYPASS BOX
1 – To Utility - H
6 – To UPS OUT - N
2 – To Utility - N
7 – To CABINET - H
3 – To UPS IN - H
8 – To UPS OUT - N
4 – To UPS IN - N
9 - Generator Input (Optional)
5 – To UPS OUT - H
Table 2: BYPASS BOX DESCRIPTIONS
1
2
3
4
5
6
7
8
9
