38
4.10.2 MODIFY RULE PARAMETERS
This menu allows you to change the parameters of each rule. Once at this screen, press the
ENTER/SHOW TIME button. To scroll thru the sixteen “Rules”, press the SELECT/MENU MODE
button.
Once at the desired “Rule”, press the arrow buttons to set new value for the “Rule”. When finished,
press the ENTER/SHOW TIME button. If you want to change another “Rule”, press the
SELECT/MENU MODE button to go to the next desired “Rule”.
Note: You can set all the “Rules” back to the default factory settings by holding both the arrow keys
down simultaneously until the screen says “Defaults are now set”. You can do this anytime you are in
the “Modify Rule Parameters” menu. All sixteen “Rules” will return to their default settings(See
table 14).
MODIFY RULE PARAM’s
RULE 02: LOW_BAT_1
New TRIP PT = 40%
