T H E C O N T I N U O U S P O W E R C O M P A N Y
40
Table 12: LIST OF RULES
#
Rule Description Parameters
00 Relay Off Turns Relay OFF. None
01 On_Bat Activates when UPS is on
Battery Mode. None (Use Rule#16 if you are using UPS in the
Offline(Standby) Mode to Cabinet Flash.)
02 Low_Bat_1 Activates when batteries reach
user settable capacity level. Set battery capacity
in %
03 Bat_Timer_1 Activates after user settable
time when UPS is in Battery
mode. Set Timer in HH:MM:SS
04 Alarms_1 Activates when Alarm
conditions occur.
See Alarm/Fault Table
Allows you to choose which alarms you want to
activate this condition. You may choose all or just
some.
05 Faults_1 Activates when Fault
conditions occur.
See Alarm/Fault Table
06 Low_Bat_2 Additional Low_Bat condition.
Functions same as Low_Bat_1. Set battery capacity in %
07 Bat_Timer_2 Additional Bat_Timer
condition. Functions same as
Bat_Timer_1.
Set Timer in HH:MM:SS
08 Alarms_2 Additional Alarm condition.
Functions same as Alarms_1. See Alarm/Fault Table
09 Faults_2 Additional Fault condition.
Functions same as Faults_1. See Alarm/Fault Table
10 Low_Bat_3 Additional Low_Bat condition.
Functions same as Low_Bat_1. Set battery capacity in %
11 Bat_Timer_3 Additional Bat_Timer
condition. Functions same as
Bat_Timer_1.
Set Timer in HH:MM:SS
12 Alarms_3 Additional Alarm condition.
Functions same as Alarms_1. See Alarm/Fault Table
13 Faults_3 Additional Fault condition.
Functions same as Faults_1. See Alarm/Fault Table
14 Fan_Ctrl_1 Activates at Temperature
levels set by user.
Set Hi/Lo limits. Choose from internal sensor or
external(Aux) sensor. There is a minimum Five°C
differential limit between the HI and Low limts.
15 Fan_Ctrl_2 Additional Fan Control
condition. Set Hi/Lo limits. Choose from internal sensor or
external(Aux) sensor.
16 UTILFAIL_IM Activates immediately when
UPS goes to battery mode.
None (Used to activate Flash when in the
Offline(Standby) Mode)
