MICR PLUS, RS-232
48
Determine if any of the conditions described above are true:
◊ If yes, rectify and continue to step 02.
◊ If no, continue to step 15.
07
Missing characters
Possible causes for this problem are:
• Character rate - the character rate at which the MICR Plus is transmitting data may be too
fast for the PC. Use SET-MICR to set the "Inter-character Delay" option to YES.
• Feeding the check - When feeding the check, make sure that the MICR line is at the bottom
and the printed side of the check is facing the MagTek logo on the MICR Plus.
Determine if any of the conditions described above are true:
◊ If yes, rectify and continue to step 02.
◊ If no, continue to step 08.
08
Communication parameters do not match
Verify that the communication parameters of the MICR Plus match the parameters of the PC.
Use SET-MICR to verify/change the communication parameters.
Determine if the condition described above is true:
◊ If yes, rectify and continue to step 02.
◊ If no, continue to step 15.
09 Incorrect
Format
Possible causes for this problem are:
• Incorrect Format Number - the current Check data format in the MICR Plus is not the desired
format. Use SET-MICR to verify/change the format.
• Incorrect Message Format - the current Message format in the MICR Plus is not the desired
format. Use SET-MICR to verify/change the Message format.
Determine if any of the conditions described above are true:
◊ If yes, rectify and continue to step 02.
◊ If no, continue to step 18.
