Section 4. Commands
13
Table 4-2. SWB Command
BIT FUNCTION
7 6 5 4 3 2 1 0
0 : No
1 : Yes
0 : No
1 : Yes
0 : No
1 : Yes
0 : No
1 : Yes
0 : No
1 : Yes
0 Send Data After Error?: No
1 Send Data After Error?: Yes
0 Send Status After Data?: No
1 Send Status After Data?: Yes
0 0 0 0 0 0 0 0 Comm Mode: 0 - Data Only
1 0 0 0 0 0 0 0 Comm Mode: 1 - Data
0 0 0 0 0 0 0 1 Comm Mode: 2 - Data -
0 0 0 0 0 0 1 1 Comm Mode: 3 - Data -
0 0 0 0 1 0 0 0 Comm Mode: 4 - Data
0 0 0 0 1 0 1 0 Comm Mode: 5 - Data
0 0 0 1 0 1 0 0 Comm Mode: 6 - Data
1 0 0 0 0 0 0 1 Comm Mode: 7 - Packet Mode
(Data)
SWB PARAMETERS
The SWB functions are listed in Table 4-2 and described below.
Control Characters and MICR Data
Control Characters may be added to the MICR data message. The characters are always in the
following locations:
data
The control characters, descriptions, and hex values are shown in Table 4-3.
