MICR PLUS, RS-232
2
ACCESSORIES
•
Interface Cable, DB-25 female, Part Number 22617504
•
Interface Cable, DB-9, female, Part Number 22617506
•
AC Power Adapter with Cable, Part Number 64300050
•
SET-MICR Demo Program, Part Number 22000020 (Rev P or higher)
•
MICR Reader Cleaning Card, Part Number 96700006
•
Sample Checks, Part Number 96530005
•
Program Mode Insta-Change check for MICR Plus, Part Number 96530022
•
Software Utility for Downloading , PROGMICR.EXE, Part Number 22596805
•
IntelliPIN Plus, portable, RS-232 interface, Part Number 30015125
•
IntelliPIN Plus, nonportable, RS-232 interface, Part Number 30015126
SPECIFICATIONS
Table 1-1 lists the specifications for the MICR Plus.
Table 1-1. Specifications
OPERATING
Reference Standards ISO/CDL/AAMVA
Power Input 120 VAC, 50/60 Hz
Output Signal Levels 12 VAC, 1 Amp
Check Read/Decode/Transit
Time 1 second
MICR fonts supported E13-B
CMC-7
MSR supported Tracks 1, 2, and 3; or Tracks 1 and 2
MECHANICAL
Dimensions Length 6.0”, Width 4.0”, Height 4.4”
Weight: 3.0 lbs. MSR and Adapter included
Cable length 6’
Connectors 9 pin DB female,
25 pin DB female
ENVIRONMENTAL
Temperature
Operating
0
o
C to 50
o
C (32
o
F to 122
o
F)
Storage -30
o
C to 70
o
C (-22
o
F to 158
o
F)
Humidity
Operating 10% to 90% noncondensing
Storage Up to 100% noncondensing
