ASSEMBLY INSTRUCTIONS FOR
Holtkötter 2000 Chandelier Collection
2009/6+3 & 2012/8+4
Major fixture parts manufactured in Germany by Holtkötter Leuchten GmbH. Final assembly by Holtkötter International, Inc. in South St. Paul, MN.
Holtkötter ® & Holtkötter Leuchten ® are registered trade-
marks of Holtkötter International, Inc. All Rights Reserved.
© Holtkötter International, Inc.
Please make sure that the following parts for your fixture are enclosed.
A column assembly consisting of:
• a threaded nipple
• brass column piece
• brass loop
• brass bobeche
A canopy kit consisting of:
• 4 feet of chain
• hanging hardware
• canopy
I. COLUMN ASSEMBLY
The fixture is pre-wired. The only things that need to be attached are the ball and the
column.
1. Push the threaded nipple over the ground wire and the fixture wire.
2. Screw the threaded nipple into the coupling at the top of the fixture.
3. Slip the brass column and bobeche over the ground and fixture wire.
4. Thread the brass loop onto the threaded nipple.
The column assembly is now complete.
II. BOTTOM BALL ASSEMBLY
The bottom ball kit includes:
• a threaded nipple
• the brass ball
• a brass finial
1. Thread the nipple into the coupling at the bottom of the fixture.
2. Slip the brass ball over the threaded nipple.
3. Thread the finial on until the brass ball is hand-tight against the fixture.
2012/8+4
III. HANGING ASSEMBLY
1. Attach the chain to the top loop of the fixture and pull the wire through the
chain.
2. Once the wire is pulled through the chain, attach the other side of the chain
to the screw collar loop and screw the fixture bar over the 1/4 IP threaded
nipple.
Now the fixture is ready to be hung.
IV. WIRING INTO THE OUTLET BOX
Connect the copper ground wire to the ground wire on the outlet box. The fixture wire
(=lamp cord) has a marked side which is rough, and an unmarked side which is
smooth. Holding your thumb over both sides of the wire, you can feel the rough and
smooth part of the wire.
The rough side of the wire connects to the white (neutral) wire in the outlet box. The
smooth side connects to the black (hot) wire in the outlet box.
