GPIB Interface Test This test verifies that the 373XXA printer interface is functioning cor-
rectly.
Equipment Required:
GPIB cable (ANRITSU PN: 2100-2), or equivalent
CAUTION
Insure that no other cables are connected to either of the
two rear panel GPIB ports when performing this test.
Procedure:
Step 1. Press the Option Menu key (Enhancement key group) to dis-
play the OPTIONS menu.
Step 2. Select DIAGNOSTICS from menu; then in sequence se-
lect: PERIPHERAL TESTS, and then GPIB INTER-
FACE. See diagram below.
Step 3. Follow instructions on the screen until test is completed.
If test fails, proceed to Chapter 5, Troubleshooting.
OPERATIONAL TESTS PERIPHERALS AND INTERFACES
373XXA MM 3-9
OPTIONS
TRIGGERS
REAR PANEL
OUTPUT
DIAGNOSTICS
MULTIPLE SOURCE
CONTROL
PRESS TO
SELECT
DIAGNOSTICS
START SELF TEST
READ SERVICE LOG
INSTALLED OPTIONS
PERIPHERAL TESTS
TROUBLESHOOTING
(FOR SERVICE
ONLY)
HW CALIBRATIONS
(FOR SERVICE
ONLY)
PRESS TO
SELECT
PERIPHERAL TESTS
CRT DISPLAY
FRONT PANEL
EXTERNAL KEY-
BOARD
PRINTER INTERFACE
GPIB INTERFACE
PREVIOUS MENU
PRESS TO
SELECT
