Front Panel Test
This test verifies that the control keys in each of the 373XXA key groups
are functioning correctly.
Procedure:
Step 1.
Press the
Option Menu
key (Enhancement key group) to dis-
play the OPTIONS menu.
Step 2.
Select DIAGNOSTICS from menu; then in sequence se-
lect: PERIPHERAL TESTS, and then FRONT PANEL.
See diagram below.
Step 3.
Follow instructions on the screen until test is completed.
If test fails, proceed to Chapter 5, Troubleshooting.
External Keyboard
Interface Test
This test verifies that the 373XXA external keyboard interface is func-
tioning correctly.
Equipment Required:
An IBM compatible keyboard is required for this test.
Procedure:
Step 1.
Press the
Option Menu
key (Enhancement key group) to dis-
play the OPTIONS menu.
Step 2.
Select DIAGNOSTICS from menu; then in sequence se-
lect: PERIPHERAL TESTS, and then EXTERNAL KEY-
BOARD. See diagram above.
Step 3.
Follow instructions on the screen until test is completed.
If test fails, proceed to Chapter 5, Troubleshooting.
Printer Interface Test
This test verifies that the 373XXA printer interface is functioning cor-
rectly.
