22 |
KDC-X998/ KDC-BT958HD/ KDC-X898/ KDC-BT858U
DSP settings (KDC-X998, KDC-BT958HD)
5-7. Delay time control
Adjusting fine tuning of the speaker position
compensation value specified at
<5-3. Car type
selection> (page 19) .
Preparation for setting
• If you specify the distance from the center of the currently
set listening position to every speaker, the delay time will
be automatically computed and set.
1. Determine the center of the currently set listening
position as the reference point (• in the illustration shown
below).
2. Measure the distances from the reference point to the
speakers.
3. Calculate the differences between the distance of the
furthest speaker and other speakers.
4. Input the differences calculated in step 3 for individual
speakers.
5. Adjust gain for individual speakers. A sound image will be
shifted to the speaker with increased gain.
Example: When “Front” is selected as the listening position
(
<5-6. Listening position setting> (page 21) ).
Front R Front L
SW R SW L
Rear R Rear L
1.7 feet
4.9 feet
+0 feet
+3.2 feet
2.6 feet
+2.3 feet
1
Press [SRC] and select a source other than
Standby (“STANDBY”) using [Control] knob.
Refer to
(page 14) .
2
Press [Control] knob.
Enters the Function setting mode.
3
Select “Audio Control” > “Pro Setup” > “DTA
Settings” > “DTA” using [Control] knob.
For how to use [Control] knob, refer to <3-3. How
to select the item> (page 13) .
4
Select a speaker using [Control] knob.
Speaker Display Range
Front Left speaker “FrontL” 0 – 20.01 feet
Front Right speaker “FrontR” 0 – 20.01 feet
Rear Left speaker “RearL” 0 – 20.01 feet
Rear Right speaker “RearR” 0 – 20.01 feet
Subwoofer Left “SW L” 0 – 20.01 feet
Subwoofer Right “SW R” 0 – 20.01 feet
( Colored text : Factory setting)
5
Select a value using [Control] knob.
Exiting from the Function setting mode
Press and hold [ 1/6].
