20 |
KDC-X998/ KDC-BT958HD/ KDC-X898/ KDC-BT858U
DSP settings (KDC-X998, KDC-BT958HD)
5-4. Speaker setting
The speaker X’Over is automatically set when the
position and size of each speaker are selected from
the following items.
1
Press [SRC] and select a source other than
Standby (“STANDBY”) using [Control] knob.
Refer to
(page 14) .
2
Press [Control] knob.
Enters the Function setting mode.
3
Select “Audio Control” > “Pro Setup” >
“Speaker Setting” using [Control] knob.
For how to use [Control] knob, refer to
<3-3. How
to select the item> (page 13) .
4
Select a speaker type using [Control] knob.
Speaker type Setting item Setting value
“Front”
Front speaker
location
“ Door ”, “On Dash”, “Under Dash”
“SIZE” Front speaker size
KDC-X998
“O.E.M.”, “3 1/2in”, “4in”, “4 3/4in”,
“5in”, “ 6 1/2in ”, “6 3/4in”, “7in”,
“4x6”, “5x7”, “6x8”, “6x9”, “7x10”
KDC-BT958HD
“Small”, “ Medium ”, “Large”
“TW” Tweeter size
“None”, “Small”, “ Medium ”, “Large”
“Rear” Rear speaker
location
“ Door ”, “Rear Deck”
(“ 2nd Row ”, “3rd Row” [1] )
“SIZE” Rear speaker size
KDC-X998
“None”, “O.E.M.”, “3 1/2in”, “4in”, “4
3/4in”, “5in”, “ 6 1/2in ”, “6 3/4in”,
“7in”, “4x6”, “5x7”, “6x8”, “6x9”,
“7x10”
KDC-BT958HD
“None”, “Small”, “ Medium ”, “Large”
“SubWoofer” “SIZE” Speaker Size Subwoofer
KDC-X998
“None”, “6 1/2inch”, “8inch”,
“ 10inch ”, “12inch”, “15inch Over”
KDC-BT958HD
“None”, “Small”, “ Large ”
( Colored text : Factory setting)
[1] Value set when “Minivan” or “Minivan (Long)” is selected
as described in <5-3. Car type selection> (page 19) .
5
Select a setting item using [Control] knob.
6
Select a setting value using [Control] knob.
Exiting from the Function setting mode
Press and hold [ 1/6].
5-5. X’Over setting
Fine adjusting the following setting values
corresponding to the X’Over values set in the
section
<5-4. Speaker setting> (page 20) .
1
Press [SRC] and select a source other than
Standby (“STANDBY”) using [Control] knob.
Refer to
(page 14) .
2
Press [Control] knob.
Enters the Function setting mode.
3
Select “Audio Control” > “Pro Setup” >
“X’Over” using [Control] knob.
For how to use [Control] knob, refer to
<3-3. How
to select the item> (page 13) .
4
Select a speaker type using [Control] knob.
Speaker type Setting item Setting value
“Front”
“FC” Front high pass filter
KDC-X998
Through , 30, 40, 50, 60, 70, 80, 90,
100, 120, 150, 180, 220, 250 Hz
KDC-BT958HD
Through , 40, 60, 70, 80, 100, 120,
150, 180, 220 Hz
“SLOPE” [1][2] Front high pass slope
-6, -12 , -18, -24 dB/Oct
“GAIN” Front gain
-8 ,-7, -6, -5, -4, -3, -2, -1, 0 dB
“Rear” “FC” Rear high pass filter
KDC-X998
Through , 30, 40, 50, 60, 70, 80, 90,
100, 120, 150, 180, 220, 250 Hz
KDC-BT958HD
Through , 40, 60, 70, 80, 100, 120,
150, 180, 220 Hz
“SLOPE” [1][2] Rear high pass slope
-6, -12 , -18, -24 dB/Oct
“GAIN” Rear Gain
-8, -7, -6, -5, -4, -3, -2, -1, 0 dB
“SubWoofer” “FC” Subwoofer low pass filter
KDC-X998
30, 40, 50, 60, 70, 80, 90, 100, 120,
150, 180, 220, 250, Through Hz
KDC-BT958HD
40, 60, 70, 80, 100, 120, 150, 180,
220, Through Hz
“SLOPE” [1][2] Subwoofer slope
-6, -12 , -18, -24 dB/Oct
“GAIN” Subwoofer gain
-8 ,-7, -6, -5, -4, -3, -2, -1, 0 dB
“PHASE” Subwoofer phase
“REV” (180°)/ “ NML ” (0°)
