Before programming the Zero or Span, the program

input must be connected to the Power Supply

Common for a minimum of 2 seconds and no more

than 6 seconds, then released for 1 second. The

LTD programming sequence is now unlocked and

will remain an unlocked unit until either the Zero or

Span is programmed or the 10 second programming

sequence times out. During the unlock mode either

the Zero or Span can be programmed by momentarily

connecting the Program Input to either the Power

Supply Common or Power Supply +.

NOTE: The LDT must be unlocked to program the

Zero and unlocked again to program the Span. Once

either the Zero or Span is programmed the LDT will go

back into the locked mode.

To program the Zero or Span, the program input must

be connected to the Power Supply Common for 4

seconds, then released for 1 second. Within the next 5

seconds, you can program either the Zero or the Span

by momentarily connecting the Program Input to either

the Power Supply Common or Power Supply +VDC.

WARNING: During normal operation,

electrically insulate the White

Program wire to prevent accidental

setting of Span.

Manual Setting of Zero & Span

To set the Zero and Span position, follow these steps:

1. Apply power to the LDT.

2. Place magnet assembly where Zero is to be

located, but within the active region of the probe.

3. Short the Program Input pin to the Power Supply

Common for 4 seconds. Remove the short for 1

second. Within 5 seconds, short the Programming

Input pin to the Power Supply Common. This

completes the Zero programming process.

4. Place magnet assembly where Span is to be

located, but within the active region of the probe.

5. Short the Program Input pin to the Power Supply

Common for 4 seconds. Remove the short for 1

second. Within 5 seconds, short the Programming

Input pin to the Power Supply +VDC.

This completes the programming process.

!

3.3: Features

Automatic Gain Control

The Automatic Gain Control feature will automatically

search and find the magnet on power up, if power is

applied without a magnet on the LDT, the LED will turn

RED indicating no magnet signal is detected. Turn

power off and place magnet within the active stroke

area. Re-apply power.

Diagnostic LED

LED Color Description

None

No power to LDT

Green

Magnet signal detected and within programmed

range.

Yellow

Magnet signal detected, but magnet is outside of

programmed range.

NOTE: Magnet can be programmed in this range

if desired.

Red

No magnet signal detected. Make sure magnet

is on the rod and within the active area. Move

magnet back into the range and cycle power.

Accessories

P/N

Description

949011L6

6 Foot, 5 Pin, Straight, 12mm, Euro Connector

949012L6

6 Foot, 5 Pin, Right Angle, 12mm, Euro Connector

SD0439700LXX 10 Pin, Straight Connector, 6 Foot Standard
SD0439700LXX 10 Pin, Right Angle Connector, 6 Foot Standard
SD0553200LXX MTS-6 Pin, "M" Option, (Voltage or Current Outputs)
SD0553300LXX Balluff-8 Pin, "B" Option, (Voltage Outputs Only)
SD0553400LXX Balluff-8 Pin, "B" Option, (Current Outputs Only)
SD0400800 Standard 4 Hole Magnet

Consult factory for complete accessory offerings.

3.4: Setting Zero & Span Position

The units come fully programmed from the factory and

do not require re-programming unless desired. The

units are 100% absolute and will not lose programmed

parameters on power loss. The Zero and Span points

can be programmed in any order and anywhere within

the LDT's active sensor area.

NOTE 1: Zero or Span can be adjusted individually

without setting the other.

NOTE 2: Zero = 0V on 0-10 VDC units and 4mA

on 4-20mA units.

There is a timing sequence that is used to unlock the

probe for programming. This is to insure that the Span

cannot be accidentally re-programmed by someone in

the field.
