44
Nominal DC Input Voltage Range 24VDC
Nominal AC Voltage / Frequency 120VAC / 60 HZ
Continuous Power Rating at 25C Ambient 2500VA
Continuous AC RMS Output at 25°C 20.8 Amps AC
Idle Power - Full AC Output ≈ 20 Watts DC
Idle Power - Search Mode 2.6 Watts DC
Typical Effi ciency 92%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 70 amps AC
Maximum Output Current - RMS (100 mSec) 50 amps AC
AC Overload Capability - Surge 6000VA
AC Overload Capability - 5 Second 4800VA
AC Overload Capability - 30 Minutes 3200VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range 80 to 150VAC
AC Input Frequency Range 54.0 to 66.0 Hz
DC Input Range 21.0 to 34.0 VDC
DC Input Current – Rated Power 125 Amps DC
Continuous Battery Charger Output 55 Amps DC
FX2524MT
FX2012MT
Nominal DC Input Voltage Range 12VDC
Nominal AC Voltage / Frequency 120VAC / 60 HZ
Continuous Power Rating at 25C Ambient 2000VA
Continuous AC RMS Output at 25°C 17.0Amps AC
Idle Power - Full AC Output ≈ 20 Watts DC
Idle Power - Search Mode 2.6 Watts DC
Typical Effi ciency 90%
Total Harmonic Distortion - Typical 2%
Output Voltage Regulation ± 2%
Maximum Output Current – Peak (1 mSec) 56 amps AC
Maximum Output Current - RMS (100 mSec) 40 amps AC
AC Overload Capability - Surge 4800VA
AC Overload Capability - 5 Second 4000VA
AC Overload Capability - 30 Minutes 2500VA
AC Input Current Maximum 30 Amps AC
AC Input Voltage Range 80 to 150VAC
AC Input Frequency Range 54.0 to 66.0 Hz
DC Input Range 10.5 to 17.0 VDC
DC Input Current – Rated Power 200 Amps DC
Continuous Battery Charger Output 100 Amps DC
