Monoprice 8745 Wireless N PoE Access Point User Manual

Page 42

4.1.3 P2MP Bridge Mode

The P2MP Bridge Mode is much like the P2P Bridge

mode, except that it allows connection between the

"Root AP" and up to four remote APs, providing

communications and network resource sharing

between the different wired networks. Because the

wireless signal is used to "bridge" the APs together, all

clients must be wired to the network or connect

wirelessly using another MW300A configured as an

Access Point.

4.1.3.1 Application and Network Topology

The P2MP bridge mode connects several wired

networks using the wireless signal as a bridge. The

main AP should be configured in P2MP Bridge mode

and the remote APs should be configured in P2P Bridge

mode. The connection diagram is shown below:
