Connect input conductors – APC InfraStruXure Power Supply User Manual
Page 24
Installation Procedures: Connect the Power Source to the PDU
16
InfraStruXure Site Planning, Installation, Start-Up
Connect input conductors
At the main input switch, connect the input
wiring according to the labels on the switch and
the illustration on this page. See the table,
“Torque specifications and tools required” on
page 15 for information about connecting to
each terminal.
A licensed electrician must connect input conductors to the PDU!
Connect the conductors to the
terminals according to the labels
on the terminals. Use copper
conductors only.
Note: This image is of a PDU with 200V input.
