Space Considerations
Study the figures below to determine your space requirements for installing the InfraStruXure PDU,
Symmetra PX UPS, and XR Battery Enclosure. Consult your local and national codes for additional
requirements.
300
Ceiling Clearance
>300mm
Front Clearance
Rear Clearance
>600mm
>1000mm
