InfraStruXure Site Planning, Installation, Start-Up
3
Site Preparation
Dimensions
InfraStruXure PDU
NetShelter VX Seismic Enclosure
Without trough: 2058mm
With trough: 2243mm
597mm
871mm
580mm
185mm
580mm
120mm
Shielding Trough
Shielding Partitions
Base Enclosure
597mm
2070mm
1072mm
Shielding Trough
185mm
580mm
Shielding Partitions
580mm
120mm
