Parts list – GReddy TURBO KITS: Mazda RX-8 2003 / T618Z User Manual
Page 4
1. Parts List
1. Turbocharger
T618Z 10cm
2
P380
1
2. Exhaust Manifold
Ductile Iron Cast
1
3. Downpipe Adapter
Ductile Iron Cast
1
4. Intercooler
Type 31C
1
5. Intercooler Bracket
(Steel)
1
6. Suction Pipe
S-1
(80
∅
-60
∅
Aluminum)
1
7.
“
S-2
(60
∅
Aluminum with flange)
1
8. Compression Pipe
C-1
(50
∅
Aluminum flange elbow )
1
9.
“
C-2
(50
∅
Aluminum)
1
10.
“
C-3
(50
∅
Aluminum)
1
11.
“
C-4
(60
∅
Aluminum elbow)
1
12.
“
C-5
(60
∅
Aluminum)
1
13.
“
C-6
(80
∅
Aluminum)
1
14. Airflow meter adapter X-4008 (Aluminum elbow)
1
15. Airinx
AY-MB (Blue)
1
16. Airinx
Hose Adapter 80
∅
1
17. "
Hose band #48
1
18. "
Bracket (Steel)
1
19. Air Pump Pressure Hose
1
20. Down Pipe Adapter Bracket
1
21. Oil Pressure
Hose SUS
(800mm)
1
22. Oil Pressure Copper Washer 10
∅
(t=1.0mm)
1
23. Oil Pressure Union Fitting
3-Way 1/8PT Fitting
1
24.
“
1/8PT – 1/8 PT Straight
1
25.
“
1/8PT – 1/8 PF Straight
1
26.
“
1/8PF – M10 P1.25
1
27. Oil Return Flange Tube
16
∅
1
28. Oil Return Fitting
16
∅
- M14 P1.5
1
29. Oil Return Copper Washer
14
∅
(t=2.0mm)
1
30. Vacuum Hose
5
∅
x 2000mm (Blue)
1
31. Rubber Hose
9
∅
x 450mm
1
32. "
16
∅
x 150mm
1
33. Rubber Hose 50
∅
x 70mm
2
34. "
60
∅
x 70mm
3
35. "
80
∅
x 60mm
1
