GReddy TURBO KITS: Scion tC 2004-05 / TD05-18G - Manual (Page 3)

1. Parts list
1. Turbocharger TD05-18G 8cm2 P560mmHg 1
2. Exhaust manifold (Stainless) 1
3. Down pipe 1 (Cast Ductile Iron) 1
4. Down pipe 2 (60φ steel) 1
5. Intercooler (TYPE 31) 1
6. Suction Pipe S-1 (80φ Aluminum) 1
7. Compression Pipe C-1 (50φ Aluminum) 1
8. “ C-2 (50φ Aluminum) 1
9. “ C-3 (60φ Aluminum) 1
10. “ C-4 (60φ Aluminum) 1
11. “ C-5 (60φ Aluminum) 1
12. Airinx AY-M (Blue Filter) 1
13. Airinx Adapter Hose (M70) 1
14. Airinx Adapter (INX-1020) 1
15. Oil Pressure Line 400mm 1
16. Oil Pressure Fitting 1/8PT-M10 P1.25 1
17. “ Copper Washer 10φ (t=1.0) 1
18. “ 3-way 1/8PT 1
19. “ 1/8PT – 1/8PT 1
20. “ 1/8PT – 1/8PF 1
21. Oil Return Flange Pipe 16φ (turbo) 1
22. Oil Return Pipe 16φ (engine) (Weld-on Type) 1
23. Hose 5φ 1000mm 1
24. “ 16φ 300mm
( Blow-by .)
1
25. “ 16φ 350mm
( Oil Return .)
1
26. Silicone Hose 50φ Straight (70mm) 2
27. “ 60φ Straight (70mm) 3
28. “ 80φ Straight (80mm) 1
29. “ 50φ-60φ Reducer 1
30. “ 60φ-65φ Reducer 1
31. “ 70φ-80φ Reducer 1
32. Hose band 10φ #5 4
33. Hose band 16φ #10 4
34. Hose band 50φ #32 5
35. Hose band 60φ #36 8
36. Hose band 65φ #40 2
37. Hose band 70φ #44 2
38. Hose band 80φ #48 3
39. Gasket Turbo Inlet （TD05） 1
