Global OBDII Diagnostics
4 – 20 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
4 4
Scan Tool starts transmitting to printer,
frame-by-frame. After all frames have
been sent, press ENTER to return to
Select Print Data screen.
Press BACK key to return to OBDII Function List.
A printout of recording might look
similar to the one shown on the
right.
Sending Frame -2
To Printer
~
---(Recorded Data)---
BATTERY(V) 12.0
COOLANT(F)
80
ENGINE RPM 0
LOOP STATUS OPEN
Frame:-1 Time:-1.1
BATTERY(V) 16.0
COOLANT(F)
90
ENGINE RPM 1000
LOOP STATUS CLSD
Frame: 0 Time:0.0
BATTERY(V) 16.0
COOLANT(F)
90
ENGINE RPM 1000
