• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 4 – 15
Global OBDII Diagnostics
4
•ISO 9141-2 protocol will be shown as ISO
•SAE J1850 protocol will be shown as VPWM OR PWM
OR
•ISO 15765-4 protocol will be shown as CAN.
NOTE: Since CAN vehicles use module ID’s larger
than 2 digits, the Scan Tool will assign a 2 digit module
ID to be used in place of the actual CAN module ID.
The Module ID assigned for the CAN Module ID will be
used in all functions of Scan Tool.
•ISO 14230-4 protocol will be shown as K2K (Keyword
2000.)
ID Protocols
$41 ISO*
$40 ISO*
ID Protocols
$10 VPWM*
ID Protocols
$10 PWM*
ID Protocols
$01 CAN*7e9
$00 CAN*7e8
ID Protocols
$10 K2K*
$1A K2K*
