Traffic Summary

Displays overall delay from traffic, a summary of incidents on the route, and the
average speed for each segment where available. You can click on any line to view
more details.

Below is an explanation of what you will see on the Traffic Alert screen:

Incidents (triangle icons) - Total number of remaining incidents directly

along the route. The color of the triangle indicates incident severity:

Color Severity

Yellow Only

Minor incidents

Orange

At least one Major incident, no
severe incidents

Red

At least one Severe incident

Delay - Total time delay caused by traffic conditions, or the sum of delays on each segment.

NOTE: Delay refers only to the route currently shown.

Go - Distance until next turn.

NOTE: This is not the distance from the origin but the length of each road segment.

Street - The street or highway name of the road segment.

Mph/Kmph - Average speed on that road segment.

NOTE: “N/A” is displayed for segments without traffic flow information (usually local streets) or segments farther than
200 miles away.

If you click on an incident line, you can view the details. Below is an explanation of
what you will see on the Traffic Detail screen:

Delay - The additional time it will take to travel the segment as

compared with the time it would take if traveling at the posted speed.

Travel Time - Estimated time it will take to travel the segment.

Slowest Speed - Slowest speed observed on the segment.

Average Speed Bar - Average speed of a segment on a scale of 0 to

the maximum-posted speed for that segment.

Incident Detail - Each incident is displayed with the following:

o

Incident icon color-coded by severity
