Cingular GPRS Raven User Guide Version 2.01 97
CHAPTER 13
Raven Specifications
Physical Characteristics:
• Weight: < 1 lb.
• Size: 3” wide x 1.1” high x 5.1" long
• Status LEDs
• RF Antenna Connector: 50 Ohm TNC
• Receive Diversity RF Antenna Connector: 50 Ohm SMA
• Serial Interface: RS232 DB-9F with
Data Services & RF Features:
• Network: 1900/850 MHz GPRS
• Transmit frequency: 1850-1910 MHz and 824-849 MHz
• Transmit power range at antenna port: 1.0 W for 1900 MHz and 0.8W for 850
MHz
• Transmitter can reduce output power when near a base station as per GSM spec-
ifications
• Receiver frequency: 1930-1990 MHz and 869-894 MHz
• Receiver sensitivity: typical -107 dBm (2.439% bit error rate)
