5.2— Progressive Timer Reset with Activation Signal
+ -
Battery
Chassis/Engine
Ground
Nitrous Arming
Switch
DPST
Fuse, 10 Amp
Fuse, 30 or
40 Amp
30
87
87A
85 86
+
-
Nitrous
Fuel Pump Ground
16 GA Black
Safety
Solenoid
Nitrous
Solenoid
Fuel
Solenoid
To Nitrous Bottle To Engine
40 Amp Relay
Launch Switch
and/or
Line Lock
Throttle Switch
Ground
20 GA Black
Ground
16 GA Black
Solenoid +12V Supply, 14GA Red
Nitrous Feed Line
N
itr
ous
S
ole
noi
d G
round,
14G
A
B
lue
Fu
el So
lenoi
d G
round,
16G
A
O
range
C NO
NC
B
att
er
y G
round,
14G
A
B
lac
k
Safety Relay Activation, 20GA Yellow
20 GA
Red
14 GA
Red
+1
2V
S
w
itc
he
d, 2
0 G
A
R
ed
20 G
A
R
ed
14 G
A
R
ed
14 G
A
R
ed
A
ctiv
atio
n +
12
V, 2
0G
A
Y
ell
ow
Note - The activation terminal has an
integrated resistor to Ground. This is to
insure that the Timing Retard Inputs of
popular Ignitions are OFF when the
Controller is NOT activated.
Timing Retard Activation
Connect to Timing
Retard Module
Activation Input
Note - The Red LED lamp should
be OFF with Arming Switch ON
and the Activation Signal OFF.
LED Lamp will blink when +12V is
applied to the Activation Terminal.
