NX #15835
Table of Contents
1.0— Important Information Page 2
2.0— Controller Description, Basics of Operation Page 3
3.0— Setting the Nitrous Power Ramp Page 4
3 .1— Setting the Start Percent Page 4
3.2— Setting the Build Time Page 4
3.3— Example Nitrous Power Graph Page 4
4.0— Installation Basics Page 5
5.0— Single Nitrous-Fuel Solenoid Installation Page 6
5.1— Hold and Wait Style Progressive Timer Page 6
5.2— Progressive Timer Reset with Activation Signal Page 7
6.0— Multiple Nitrous-Fuel Solenoid Installation Page 8
6.1— Hold and Wait Style Progressive Timer Page 8
6.2— Progressive Timer Reset with Activation Signal Page 9
7.0— Testing Controller Operation and Trouble Shooting Page 10
8.0— Specifications Page 11
9.0— Warranty Page 11
1.0— Important Information - Must use Static Suppression Ignition Wires with this
Controller. The NX #15835 Nitrous Controller contains High Frequency Digital Electronics
and will NOT function correctly without Suppression Wires!
Caution -
Do NOT submerge Controller in liquid or directly wash unit with liquid of any
type! (Do NOT spray when washing vehicle!)
Warning -
The Programming Switches are Delicate Electronic items and can be damaged
by misuse and/or carelessness. If the Controller is close to your Nitrous Bottle be careful
when installing the bottle. The weight of the bottle is enough to easily damage the switches.
Switches that have been determined to be damaged due to neglect will NOT be covered un-
der Warranty.
It is the responsibility of the purchaser to follow all guidelines and safety procedures
supplied with this product and any other manufactures product used with this product. It is
also the responsibility of the purchaser to determine compatibility of this device with the
vehicle and other components.
Nitrous Express assumes no responsibility for damages resulting from accident, im-
proper installation, misuse, abuse, improper operation, lack of reasonable care, or all previ-
ously stated reasons due to incompatibility with other manufacturer's products.
Nitrous Express assumes no responsibility or liability for damages incurred from the
use of products manufactured or sold by Nitrous Express on vehicles used for competition
racing. Nitrous Express neither recommends nor approves the use of products manufac-
tured or sold by Nitrous Express on vehicles which may be driven on public highways or
roads, and assumes no responsibility for damages incurred from such use.
It is the purchaser’s responsibility to check the state and local laws pertaining to the
use of Nitrous Oxide for racing applications. Nitrous Express does not recommend nor con-
done the use of its products for illegal street racing.
