Flex-a-Lite 240 Pusher Fan User Manual
Installation instructions, Pusher fans

(SEE DIAGRAM Below )
Step 1. Attach frame mounting brackets to fan using the 4 3/4 ''self tapping screw.
Step 2. Position fan to desired location, mark holes on radiator channels or frame.
Step 3. Rotate fan blades to insure that they are free of obstruction.
Step 4. On the marked hole locations drill 13/64" holes.
Step 5. Secure the fan to radiator using the provided 1/4" x 1" self tapping screws.
Step 6. Check fan rotation.
130 & 230 140 & 240
Pusher Fans
Model 130 - Single fan w/ thermostatic
control & A/C relay
Model 140 - Single fan w/o thermostatic
control & A/C relay
Model 230- Dual fan w/ thermostatic
control & A/C relay
Model 240 - Dual fan w/o thermostatic
control & A/C relay
rev. 05-01-08 99875
Page 1 of 3
Installation Instructions
