Chapter 3: Terminal Menu Operation and Structure
61202192L1-1 Express L768/L1.5 User Manual 75
Status/IPX Routes
Read security: 5
This lists the contents of the Express L768/L1.5’s IPX router table.
IPX Routes /Network - Network destination address
IPX Routes /Gateway - Node or Ethernet address of gateway to
receive this packet
IPX Routes /Port - Port gateway is located on:
local - sent directly to the Express L768/L1.5 router
eth0 - Express L768/L1.5’s ethernet port
wan0 - Express L768/L1.5’s first PPP bundle
fr 0 . . . fr 9 - Express L768/L1.5 is connected up to 10 DLCIs
IPX Routes /Use - Number of times the Express L768/L1.5 has
referenced the route
IPX Routes/Hops - Number of routers that must go through to get to
destination. Ranges from 0-15 or 16 for infinite (can’t get there
from here).
IPX Routes/Ticks - Router determined value for representing time
packets take to reach the network destination. One tick is equivalent
to one-eighteenth of a second.
IPX Routes/TTL - Seconds until address is removed from table.
Value of 999 means route is static.
Status/IPX Servers
Read security: 5
This lists the contents of the Express L768/L1.5’s IPX server table.
IPX Servers/Type - The server type
IPX Servers/Name - The server name
IPX Servers/Network - The server network address
IPX Servers /Address - The servers node address
IPX Servers/Socket - The servers socket address
