Appendix B: Log Messages
94 Express L768/L1.5 User Manual 61202192L1-1
Peer failed PAP authen
level 3
The PPP peer’s reported PAP username and/or password does not match the
Express L768/L1.5’s parameters. This is most likely caused by PPP peer send-
ing incorrect username and/or password. Make sure the Configuration/Con-
nection List/Authentication
parameters Rx Username and Rx Password are
correctly entered. Also, if using RADIUS, check that the server is configured
and running properly.
Peer refused authen
level 3
The PPP peer would not allow the Express L768/L1.5 to authenticate it using
the method set in Configuration/Security/PPP.
Peer refused SpanTree
level 4
The PPP peer would not participate in the Spanning Tree protocol. This is a
warning message only. Bridging will still occur across the WAN port so care
must be taken that no loop topologies exist across the connection.
PPPtx[x] …
level 6
Advance debugging decode of transmitted PPP configuration packets.
PPPrx[x] …
level 6
Advanced debugging decode of received PPP configuration packets.
Call Log Messages
Power Up - last down cause:
level 0 (displayed as level 1 after the unit is reset)
This is the for the last reset. Most are caused by internal errors. Pos-
sible reasons are:
Bus Error - Bad address occurred on the internal bus
Kernel error - General operating system error
No SBCs - Mail resources used up or lost
