ADTRAN L768 User Manual
Page 32
Chapter 3: Terminal Menu Operation and Structure
16
Express L768/L1.5 User Manual
61202192L1-1
Figure 3-1
Top Level Terminal Menu
Menu Path
Describes the current
position in the terminal
menu structure.
Right Pane
Lists available submenus. Additional
submenus available through this pane
are indicated by the [+] and [DATA]
symbols.
Left Pane
Lists available
menus.
Mode
Describes current
operating mode.
Loop Status
Displays current
status of HDSL line.
Rate Status
Displays current rate
of connection.
Navigation Help
Displays list of
characters you can
use to navigate the
terminal menus.
Press Control-Z.
System Time
Displays the cur-
rent time. See Date/
Time on page 23 for
details on setting
the time.
