FRONT SWAY BAR INSTALLATION (Continued)
SB016 – 2010-2012 CHEVROLET CAMARO
7. Begin sliding the BMR sway bar in from the
passenger side the same way the OE bar was removed.
Rotate and slide the bar in a spiral pattern until it gets
to the drivers side. (IMAGE 5)
8. Grease the inside of the BMR polyurethane bushings.
Position the bushings over the straight section of the
sway bar. The bushings go to the outside of the
welded thrust washers on the sway bar.
9. Place the provided bushing saddle over the
polyurethane bushings and thread the OE nuts into
place. Tighten.
10. Connect the outer end links to the sway bar and
tighten.
11. Lower the engine and re-tighten the mounting nuts.
12. Grease the fittings on the sway bar mounting bushings until grease is visible protruding from the bushing.
13. If you have a ZL1, re-install the underbody plastic covers.
14. Re-install wheels, tires and lower vehicle.
