BMR Suspension BK017 User Manual
BMR Suspension For the car
Rear Upper Control Arm Bushing
BK017
Required Tools:
Hydraulic jack and 2 stands (lift optional but recommended)
Wrenches – 18mm, 21mm
Sockets – 10mm, 13mm, 18mm, 21mm
Pry-bar
Installation:
1. Lift vehicle and support with stands under the rocker jack points as shown in
Image 1 below.
2. Remove both rear wheels.
3. Using a 15mm socket, remove the driveshaft tunnel brace. See Image 2.
4. Using a 15mm socket, loosen the
exhaust clamps at the front of the
exhaust.
5. Using a helper, slide the rear muffler
mounts off the mounting dowels
(Image 3) and then pull the entire
exhaust assembly rearward and out of
the car.
Continued
