Appendix d: console port pin outs – Asante Technologies 35516 User Manual
Page 110
- 110 -
Appendix D: Console Port Pin Outs
The console port is used to connect with a terminal using a serial modem RS-232C cable (available from Radio
Shack’s website,
www.radioshack.com
, catalog # 26-117). The setting is 9600-N81. The table below lists the pin
outs.
Pin Number
Signal
Name
1
CD
Carrier Detect
2
RD
Receive Data
3
TD
Transmit Data
4
DTR
Data Terminal Ready
5
SG
Signal Ground
6
DSR
Data Set Ready
7
RTS
Request to Send
8
CD
Carrier Detect
9
RI
Ring Indicator
