• 128 KB internal packet buffer
• Full duplex 1000 Mbps, full and half duplex 10/100 Mbps
• Support for Jumbo Frames (up to 32 KB in length)
1.2 Package Contents
The following items are included in the switch’s package:
• Switch
• AC power cord
• Rackmount brackets with screws
• Rubber feet
• Setup Guide
• IntraCore 35516 CD-ROM
Contact your dealer immediately if any of these items is missing.
1.3 LEDs
The system’s front panel LED display allows you to monitor the status of the switch. Refer to the following sections for
LED information specific to the switch’s model.
1.3.1 IC35516-T
The IC35516-T has one power LED indicator, one (optional) emergency power LED, and two LED indicators for each
of the 16 ports. See the table below for a complete LED description.
LED Color Description
Power Green
Off
Power is on.
Power is off, or main power has failed.
Emergency Power Green
Off
Primary power has failed and optional power supply is powering the switch.
Optional power supply is in standby mode and primary power is working.
Link/Speed Green
Yellow
Off
A valid 1000 Mbps link has been established on the port.
A valid 10/100 Mbps link has been established on the port.
No link has been established on the port.
