Identifying parts – HP LaserJet Print to Mail Accessories User Manual
Page 10
8 2 Setup
EN
Identifying parts
Before you begin to set up the HP LaserJet Print to Mail accessory,
identify the following parts of the accessory:
Figure 2.
Front view
Figure 3.
Rear view
bottom of the alignment guide)
Accessory interface cable (C-Link)
Alignment
Alignment tips (on the
Power
connector
guide
Upper
fold-chute
slot
Output bin slot
Lower fold-chute slot
Reversible base
Power switch
Top cover
Jam-clearing knob
Serial number plate
(inside output bin slot)
