Hardware options installation 57
13. Install the drives.
14. Install blanks in unused drive bays.
15. Connect each power cord to the server.
16. Connect each power cord to the power source.
SAS controller cable option
The SAS controller cable option is required to enable a PCIe slot-based controller to drive the internal top bay
drives. Otherwise, the drive indicator signaling will not correctly match the accessed drive. The bottom bay
SAS drives cannot be controlled by a PCIe slot-based controller.
CAUTION: To prevent damage to electrical components, take the appropriate anti-static
precautions before beginning any system installation. Improper grounding can cause electrostatic
discharge.
To install the component:
1. Power down the server (on page 23 ).
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Remove the access panel (on page 27 ).
