Hardware options installation 44
18.
Memory cartridge option
Memory cartridge population guidelines
When installing memory cartridges, observe the following guidelines:
•
Memory cartridges installed without a corresponding processor are not utilized:
o
Processor 1 corresponds to memory cartridges 1 and 2.
o
Processor 2 corresponds to memory cartridges 3 and 4.
o
Processor 3 corresponds to memory cartridges 5 and 6.
Memory cartridges 5 and 6 are not recognized if processor 3 is not installed.
o
Processor 4 corresponds to memory cartridges 7 and 8.
•
To maximize performance, install two memory cartridges per processor and balance the total memory
capacity between all installed processors.
•
UDIMMs are not supported.
•
Install DIMMs in pairs and in alphabetical order: A & B, C & D, E & F …
•
Do not mix LRDIMMs with any other DIMM type (RDIMM, LVDIMM).
•
RDIMM population is limited to a maximum of eight logical ranks per channel. Therefore, only two quad
rank RDIMMs are supported per channel. If there are more than eight physical ranks per channel,
LRDIMMs rank multiplication provides support for three DIMMs per channel.
•
1:1 Lockstep mode requires specific population requirements. For more information, see "Memory
configurations (on page
)."
Installing a memory cartridge
WARNING:
Use caution when installing or removing the processor memory drawer. The
processor memory drawer is very heavy when fully populated.
To install the component:
1.
Power down the server (on page
2.
Remove all power:
a.
Disconnect each power cord from the power source.
b.
Disconnect each power cord from the server.
3.
Remove the processor memory drawer shipping screws, if installed. Retain the screws for future use
("
Processor memory drawer shipping screw locations
" on page
4.
Remove the processor memory drawer (on page
5.
