Hardware options installation 34
3. Install the hard drive.
IMPORTANT: When the drive is inserted, the drive LEDs flash for 2 seconds to indicate that the
drive is seated properly and receiving power.
4. Determine the status of the hard drive from the SAS and SATA hard drive LED combinations (on
page
9 ).
Installing an expansion board
1. Power down the server (on page 26 ).
2. Remove the access panel (" Removing and replacing the access panel " on page 26 ).
3. Remove the upper tray (" Removing the upper tray " on page 27 ).
4. Remove the PCI riser board assembly (" Removing the PCI riser board assembly " on page 28 ).
5. Install the expansion board.
