Setup 23
• Phillips screwdriver
• Hardware options
• Operating system or application software
• Keyboard
• Mouse
• External USB CD-ROM drive
• External USB floppy drive
• USB key
Installing a storage enclosure into the rack
To install the server into the rack:
1. Secure the front end of the rails to the rack.
IMPORTANT: Do not remove the pins from the ends of the rack rails unless you are converting
the rails for use in round-hole racks. These load-bearing pins are designed to fit through the
holes without being removed.
IMPORTANT: Be sure that the scissor-type locking latches engage the rack fully when the pins
extend through the holes marked with the template.
NOTE: Identify the left (L) and right (R) rack rails by markings stamped into the sheet metal.
2. Secure the back end of the rails to the rack.
IMPORTANT: Be sure that the scissor-type locking latches engage the rack fully when the pins
extend through the holes marked with the template.
