Page 40: Locating the reset button
About the reset button
The Brocade 8Gb SAN Switch integrates a Reset button, (
). The Reset button is a small,
recessed micro-switch that is accessed by inserting a pin (or object of similar size) in the small hole.
Use the Reset button to reboot the switch.
Figure 9 Locating the Reset button
.
Table 17 Locating the reset button
Description
Item
Port side of switch
1
Reset button
2
Rebooting the switch
Depress the Reset button for up to 5 seconds to reboot the switch.
Replacing a faulty 8Gb SAN Switch
To replace a faulty switch in the c-Class enclosure:
IMPORTANT:
For supplemental information on any of these steps, refer to the latest
HP StorageWorks Fabric OS
administrator guide and Fabric OS Advanced Web Tools administrator guide, available at the HP
website:
nl
To access the guides, scroll to the storage section of the web page, and select Storage Networking
for HP StorageWorks products.
In addition to these guides, refer to the Brocade 8Gb SAN Switch for HP c Class BladeSystem—Setup,
Configuration and Installation Procedures available on
for initial installation
instructions of the new switch.
Managing the 8Gb SAN Switch
40
