Installing an internal DAT tape drive

22

4.

If the drive is the last device on the SCSI chain, make sure that the SCSI cable is terminated

correctly.

Figure 8

Connecting power and SCSI cables

1 and 7

terminated SCSI cable

2 and 4

power cable

3

tape drive

5

server’s power supply

6

SCSI controller

1

2

3

4

5

6

7
