HP Integrity NonStop H-Series - Manual (Page 3)

Hewlett-Packard Company— 524959-003
i
9840 (CT9840FC-3)
Installation and User’s
Guide for the NonStop S-
Series Enclosure
Glossary Index Examples Figures Tables
What’s New in This Manual v
Manual Information v
New and Changed Information v
About This Manual vii
Notation Conventions vii
1. Product Overview
Overview 1-1
CT9840FC-3 Tape Drive 1-1
Tape Drive Configuration With Fibre Channel Converter 1-1
Specifications 1-4
Operator Panel 1-5
Operator Panel Indicators 1-8
NonStop S-series Tape Enclosure 1-9
Dimensions 1-9
Rear Cover 1-11
Configuration Options 1-12
9840 Tape Cartridges 1-15
High Capacity Tape Cartridge 1-18
Durability 1-18
Volsafe Secure Media Technology 1-18
2. Installing the Tape Drive
Overview 2-1
Attaching the Power Cord 2-1
Installing the SCSI Interface Cable 2-2
Installing Multimode Fiber Cables 2-3
To Install Multimode Fiber Cables 2-3
Powering On the Tape Drive and the Fibre Channel Converter 2-4
Installing the Rear Cover 2-5
